Name: Property Info

Display Field: OwnerName

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This dataset represents a compilation of data from various government agencies throughout the City of New York. The underlying geography is derived from the Tax Lot Polygon feature class that is part of the Department of Finance's Digital Tax Map (DTM). The tax lots have been clipped to the shoreline, as defined by NYCMap planimetric features. The attribute information is from the Department of City Planning's PLUTO data. The attribute data pertains to tax lot and building characteristics and geographic, political and administrative information for each tax lot in New York City.The Tax Lot Polygon feature class and PLUTO are derived from different sources. As a result, some PLUTO records do not have a corresponding tax lot in the Tax Lot polygon feature class at the time of release. These records are included in a separate non-geographic PLUTO Only table. There are a number of reasons why there can be a tax lot in PLUTO that does not match the DTM; the most common reason is that the various source files are maintained by different departments and divisions with varying update cycles and criteria for adding and removing records. The attribute definitions for the PLUTO Only table are the same as those for MapPLUTO. DCP Mapping Lots includes some features that are not on the tax maps. They have been added by DCP for cartographic purposes. They include street center 'malls', traffic islands and some built streets through parks. These features have very few associated attributes.To report problems, please open a GitHub issue or email DCPOpendata@planning.nyc.gov.</SPAN></P></DIV></DIV></DIV>

Service Item Id: e80883aa972f4f55a841a47a999061b0

Copyright Text: NYC Department of City Planning, Information Technology Division

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1010912.1947088242
YMin: 165858.08177900314
XMax: 1028811.2400026321
YMax: 192528.33860635757
Spatial Reference: 102718  (2263)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [130, 130, 130, 0]
Outline:
Style: esriSLSSolid
Color: [0, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 750.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Borough ( type: esriFieldTypeString, alias: Borough, length: 2 )
• Block ( type: esriFieldTypeInteger, alias: Block )
• Lot ( type: esriFieldTypeSmallInteger, alias: Lot )
• CD ( type: esriFieldTypeSmallInteger, alias: CD )
• BCT2020 ( type: esriFieldTypeString, alias: BCT2020, length: 7 )
• BCTCB2020 ( type: esriFieldTypeString, alias: BCTCB2020, length: 11 )
• CT2010 ( type: esriFieldTypeString, alias: CT2010, length: 7 )
• CB2010 ( type: esriFieldTypeString, alias: CB2010, length: 5 )
• SchoolDist ( type: esriFieldTypeString, alias: SchoolDist, length: 3 )
• Council ( type: esriFieldTypeSmallInteger, alias: Council )
• ZipCode ( type: esriFieldTypeInteger, alias: ZipCode )
• FireComp ( type: esriFieldTypeString, alias: FireComp, length: 4 )
• PolicePrct ( type: esriFieldTypeSmallInteger, alias: PolicePrct )
• HealthCenterDistrict ( type: esriFieldTypeSmallInteger, alias: HealthCenterDistrict )
• HealthArea ( type: esriFieldTypeSmallInteger, alias: HealthArea )
• Sanitboro ( type: esriFieldTypeString, alias: Sanitboro, length: 2 )
• SanitDistrict ( type: esriFieldTypeString, alias: SanitDistrict, length: 2 )
• SanitSub ( type: esriFieldTypeString, alias: SanitSub, length: 2 )
• Address ( type: esriFieldTypeString, alias: Address, length: 39 )
• ZoneDist1 ( type: esriFieldTypeString, alias: ZoneDist1, length: 9 )
• ZoneDist2 ( type: esriFieldTypeString, alias: ZoneDist2, length: 9 )
• ZoneDist3 ( type: esriFieldTypeString, alias: ZoneDist3, length: 9 )
• ZoneDist4 ( type: esriFieldTypeString, alias: ZoneDist4, length: 9 )
• Overlay1 ( type: esriFieldTypeString, alias: Overlay1, length: 4 )
• Overlay2 ( type: esriFieldTypeString, alias: Overlay2, length: 4 )
• SPDist1 ( type: esriFieldTypeString, alias: SPDist1, length: 12 )
• SPDist2 ( type: esriFieldTypeString, alias: SPDist2, length: 12 )
• SPDist3 ( type: esriFieldTypeString, alias: SPDist3, length: 12 )
• LtdHeight ( type: esriFieldTypeString, alias: LtdHeight, length: 5 )
• SplitZone ( type: esriFieldTypeString, alias: SplitZone, length: 1 )
• BldgClass ( type: esriFieldTypeString, alias: BldgClass, length: 2 )
• LandUse ( type: esriFieldTypeString, alias: LandUse, length: 2 )
• Easements ( type: esriFieldTypeSmallInteger, alias: Easements )
• OwnerType ( type: esriFieldTypeString, alias: OwnerType, length: 1 )
• OwnerName ( type: esriFieldTypeString, alias: OwnerName, length: 85 )
• LotArea ( type: esriFieldTypeInteger, alias: LotArea )
• BldgArea ( type: esriFieldTypeInteger, alias: BldgArea )
• ComArea ( type: esriFieldTypeInteger, alias: ComArea )
• ResArea ( type: esriFieldTypeInteger, alias: ResArea )
• OfficeArea ( type: esriFieldTypeInteger, alias: OfficeArea )
• RetailArea ( type: esriFieldTypeInteger, alias: RetailArea )
• GarageArea ( type: esriFieldTypeInteger, alias: GarageArea )
• StrgeArea ( type: esriFieldTypeInteger, alias: StrgeArea )
• FactryArea ( type: esriFieldTypeInteger, alias: FactryArea )
• OtherArea ( type: esriFieldTypeInteger, alias: OtherArea )
• AreaSource ( type: esriFieldTypeString, alias: AreaSource, length: 1 )
• NumBldgs ( type: esriFieldTypeInteger, alias: NumBldgs )
• NumFloors ( type: esriFieldTypeDouble, alias: NumFloors )
• UnitsRes ( type: esriFieldTypeInteger, alias: UnitsRes )
• UnitsTotal ( type: esriFieldTypeInteger, alias: UnitsTotal )
• LotFront ( type: esriFieldTypeDouble, alias: LotFront )
• LotDepth ( type: esriFieldTypeDouble, alias: LotDepth )
• BldgFront ( type: esriFieldTypeDouble, alias: BldgFront )
• BldgDepth ( type: esriFieldTypeDouble, alias: BldgDepth )
• Ext ( type: esriFieldTypeString, alias: Ext, length: 2 )
• ProxCode ( type: esriFieldTypeString, alias: ProxCode, length: 1 )
• IrrLotCode ( type: esriFieldTypeString, alias: IrrLotCode, length: 1 )
• LotType ( type: esriFieldTypeString, alias: LotType, length: 1 )
• BsmtCode ( type: esriFieldTypeString, alias: BsmtCode, length: 1 )
• AssessLand ( type: esriFieldTypeDouble, alias: AssessLand )
• AssessTot ( type: esriFieldTypeDouble, alias: AssessTot )
• ExemptTot ( type: esriFieldTypeDouble, alias: ExemptTot )
• YearBuilt ( type: esriFieldTypeSmallInteger, alias: YearBuilt )
• YearAlter1 ( type: esriFieldTypeSmallInteger, alias: YearAlter1 )
• YearAlter2 ( type: esriFieldTypeSmallInteger, alias: YearAlter2 )
• HistDist ( type: esriFieldTypeString, alias: HistDist, length: 66 )
• Landmark ( type: esriFieldTypeString, alias: Landmark, length: 150 )
• BuiltFAR ( type: esriFieldTypeDouble, alias: BuiltFAR )
• ResidFAR ( type: esriFieldTypeDouble, alias: ResidFAR )
• CommFAR ( type: esriFieldTypeDouble, alias: CommFAR )
• FacilFAR ( type: esriFieldTypeDouble, alias: FacilFAR )
• BoroCode ( type: esriFieldTypeInteger, alias: BoroCode )
• BBL ( type: esriFieldTypeDouble, alias: BBL )
• CondoNo ( type: esriFieldTypeInteger, alias: CondoNo )
• Tract2010 ( type: esriFieldTypeString, alias: Tract2010, length: 7 )
• XCoord ( type: esriFieldTypeInteger, alias: XCoord )
• YCoord ( type: esriFieldTypeInteger, alias: YCoord )
• ZoneMap ( type: esriFieldTypeString, alias: ZoneMap, length: 3 )
• ZMCode ( type: esriFieldTypeString, alias: ZMCode, length: 1 )
• Sanborn ( type: esriFieldTypeString, alias: Sanborn, length: 8 )
• TaxMap ( type: esriFieldTypeString, alias: TaxMap, length: 5 )
• EDesigNum ( type: esriFieldTypeString, alias: EDesigNum, length: 5 )
• APPBBL ( type: esriFieldTypeDouble, alias: APPBBL )
• APPDate ( type: esriFieldTypeString, alias: APPDate, length: 10 )
• PLUTOMapID ( type: esriFieldTypeString, alias: PLUTOMapID, length: 1 )
• FIRM07_FLAG ( type: esriFieldTypeString, alias: FIRM07_FLAG, length: 1 )
• PFIRM15_FLAG ( type: esriFieldTypeString, alias: PFIRM15_FLAG, length: 1 )
• Version ( type: esriFieldTypeString, alias: Version, length: 6 )
• DCPEdited ( type: esriFieldTypeString, alias: DCPEdited, length: 3 )
• Latitude ( type: esriFieldTypeDouble, alias: Latitude )
• Longitude ( type: esriFieldTypeDouble, alias: Longitude )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 20 )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
